ARC-1029P-WTR Dual Scalable Xeon Socket 3647 Server with Redundant Power 1U Rackmount
- Web Server, Firewall Apps
- Corporate-Wins, DNS, Print, Login
- Gateway, provisioning servers
- Compact Network Appliance
- Cloud Computing
- Get a Quote :
|
|
The ARC-1029P-WTR features dual Intel Xeon Scalable processors for processing intesive application in a compact 1U rackmount platform. Availble with
8 removable 2.5" disk bays and high capacity memory configuration.
|
Specification |
ARC-1029P-WTR |
| Chassis | 1U Rackmount |
| CPU |
Dual Socket P (LGA 3647) 2nd Gen. Intel Xeon Scalable Processors (Casacade Lake/Skylake), Dual UPI up to 10.4GT/s Support CPU TDP 70-165W |
| Chipset |
Intel C621 Chipset |
| Slot |
2 PCI-E 3.0 x16 (FHHL) slots 1 PCI-E 3.0 x8 (LP) slot 1 PCI-E 3.0 x4 NVMe M.2 slot |
| VGA | ASPEED AST2500 BMC |
| Memory |
12 DIMM slots Up to 3TB 3DS ECC DDR4-2933MHz RDIMM/LRDIMM |
| HDD | 8 Hot-swap 2.5" drive bays |
| Optical | 1 Slim DVD-ROM drive bay |
| Interface | 1 VGA port, 4 USB 3.0 ports (rear), 2 RJ45 Gigabit Ethernet ports, 1 RJ45 Dedicated IPMI LAN port |
| LAN | 2 1GbE LAN port via Intel® X722 |
| Power Supply |
750W Redundant Power Supplies Platinum Level High-efficiency 100~240VAC, Auto switch |
| Fan | 4 Counter-rotating 4cm PWM fans |
| Dimension | 17.2"Wx 1.7"Hx 23.5"D |
| Weight | 46 lbs (20.9 kgs) |
|
Environment |
Operating | Non-Operating |
| Temperature | 10°C~50°C | -40°C~60°C |
| Relative Humidity | 8%~90% | 5%~95% |
| Approval | RoHS Compliant | |
