ARC-5019S-ML Compact Xeon / Core Server 1U Rackmount
- Mainstream, Entry Appliance
- Low Power, Cost effective
- Get a Quote :
|
|
The ARC-5019S-ML 1U Rackmount server offer a compact and cost effective solution for entry appliance. The server readily accept Xeon, Core i3, Pentium and Celeron processor.
Available with internal 3.5" or 2.5" storage option and single PCI-E slot expansion.
|
Specification |
ARC-5019S-ML |
| Chassis | 1U Rackmount |
| CPU |
Single Socket H4 (LGA 1151) Supports Intel Xeon processor E3-1200 v6/v5, Intel 7th/6th Gen Core i3 / Pentium / Celeron Support CPU TDP 80W |
| Chipset |
Intel C236 Chipset |
| Slot |
1 PCI-E 3.0 x8 (FHHL) slots 1 PCI-E 3.0 x2 M.2 slot |
| VGA | ASPEED AST2400 BMC |
| Memory |
4 DIMM slots Up to 64GB DDR4 ECC UDIMM 2400MHz |
| HDD | 2 Fixed 3.5" drive bay or 3x 2.5" drive option |
| Optical | 1 Slim DVD-ROM drive bay |
| Interface |
1 VGA port, 1 COM port, 2 USB 3.0 ports (rear), 2 USB
3.0 ports (front), 2 USB 2.0 ports (rear) 2 RJ45 Gigabit Ethernet ports, 1 RJ45 Dedicated IPMI LAN port |
| LAN | 2 1GbE LAN port via Intel® I210-AT |
| Power Supply |
350W Power Supplies Platinum Level High-efficiency 100~240VAC, Auto switch |
| Fan | 2 Counter-rotting 4cm PWM fans |
| Dimension | 17.2"Wx 1.7"Hx 14.4"D |
| Weight | 16 lbs (7.3 kgs) |
|
Environment |
Operating | Non-Operating |
| Temperature | 10°C~50°C | -40°C~60°C |
| Relative Humidity | 8%~90% | 5%~95% |
| Approval | RoHS Compliant | |
